Fe Faith AmpCore™ HQ22 DC Charger – 22kW

Fe Faith AmpCore™ HQ22 DC Charger – 22kW

Power up your EV charging capabilities with the FE-FAITH Wattsaving HQ22 22kW DC Charger—a high-performance, smart DC charging solution built for speed, reliability, and safety. Designed to deliver up to 22kW of efficient DC power, this charger is perfect for residential or commercial use, supporting a wide output voltage range of 200–1000Vdc. With built-in 4G and Bluetooth connectivity, the HQ22 offers advanced monitoring and control features. A rugged IP54-rated build, comprehensive protection system, and multiple cable length options make this charger a powerful, versatile, and future-ready EV charging solution.
Comparable to: ABB Terra 22 kW, Siemens VersiCharge (based on charging speed and smart connectivity).

What It Does

The Fe Faith AmpCore™ HQ22 DC Charger provides ultra-fast EV charging with up to 22kW of DC power. This charger supports a broad voltage range (200–1000Vdc), making it compatible with a wide range of EV models. Its smart connectivity features, including 4G and Bluetooth, enable easy remote monitoring and control. The charger is built with durability in mind, featuring an IP54-rated enclosure for both residential and sheltered outdoor installation. It also includes advanced safety features to protect your EV and charger during use.

Key Features:

• Ultra-Fast Charging: Delivers up to 22kW of DC power for rapid EV charging.

• Smart Connectivity: 4G and Bluetooth communication for easy control and updates.

• Wide Voltage Range: Compatible with 200–1000Vdc output, supporting a broad range of EV models.

• Enhanced Safety Protections: Includes overcurrent, surge, temperature, and ground protection for safe and reliable operation.

• Durable & Weather-Resistant: IP54-rated enclosure ensures performance in both residential and sheltered outdoor environments.

Specifications:

• Model: Wattsaving HQ22

• Output DC Power: Maximum 22 kW

• Input Voltage: 323~480Vac, 380Vac Type

• Output Voltage: 200~1000Vdc

• Frequency: 45-55Hz

• Current: 67A MAX

• Efficiency: ≥94%

• Communication: 4G/Bluetooth

• Cable Length: 5m/8m

• Input Wiring: Hardwired

• Display: 1.52" LCD Screen

• Input Cord (three-phase): L1, L2, L3, N (Neutral), and PE (Protective Earth)

• Protection: Overcurrent protection, Residual current protection, Ground protection, Surge protection, Over/Under Voltage protection, Over/Under temperature protection.

• IP Rated: IP54

• Storage Temperature: -40 to 80℃

• Operating Temperature: -30℃~65℃

• Operating Humidity: 5%~95%

• Connector: 1

• Standards:

  • GB/T 18487.1-2015

  • GB/T 27930-2015

  • NB/T 33001-2018

  • NB/T 33008.1-2018

• Dimensions (H x W x D): 590 x 150 x 162mm

• Weight: 18.0kg

Compatible With

Ideal for residential and commercial use, compatible with a wide range of electric vehicle models due to its broad voltage range and high-power output.

Comparable To

ABB Terra 22 kW, Siemens VersiCharge (based on charging speed and smart connectivity).

Disclaimer

Ensure proper installation according to the manufacturer’s guidelines. Specifications are subject to change without notice.
