Fe Faith AmpCore™ T30 DC Fast Charger – 30kW

Fe Faith AmpCore™ T30 DC Fast Charger – 30kW

Power up your EV experience with the FE-FAITH Wattsaving T30 30kW DC Fast Charger, designed to deliver rapid, efficient, and secure electric vehicle charging. Whether you're installing it in a residential garage or a commercial facility, this charger ensures consistent high-speed performance with smart safety protection. With advanced 4G communication, a durable build, and broad compatibility, it's a dependable solution for today’s EV needs.
Comparable to: ABB Terra 30 kW, Siemens VersiCharge Ultra (based on fast charging, safety features, and communication capabilities).

What It Does

The Fe Faith AmpCore™ T30 DC Fast Charger provides ultra-fast, 30kW DC charging for a wide range of electric vehicles. It supports a broad voltage range (200–1000V DC) for compatibility with multiple EV models. The charger includes advanced 4G communication for real-time monitoring and diagnostics, ensuring a smooth and secure charging experience. Its IP54-rated design allows for installation both indoors and outdoors, providing durability in challenging environments.

Key Features:

• High-Speed Charging: Delivers up to 30kW DC output, enabling faster EV charging with reduced wait times.

• Smart Communication: Built-in 4G connectivity for real-time monitoring and remote diagnostics.

• Enhanced Safety: Includes overcurrent, surge, voltage, and temperature protections to ensure secure operation.

• Wide Voltage Range: Supports 200–1000V DC output, making it compatible with a wide range of EVs.

• Durable Design: IP54-rated for safe indoor and outdoor installation with robust performance in extreme conditions.

• User-Friendly Display: Integrated LCD screen for easy access to real-time charging data.

• Flexible Installation: Supports hardwired three-phase connections for stable and powerful charging.

Specifications:

• Model: Wattsaving T30

• Output DC Power: Maximum 30 kW

• Input Voltage: 323~500Vac, 380Vac Type

• Output Voltage: 200~1000Vdc

• Frequency: 45-55Hz

• Current: 125A MAX

• Efficiency: ≥94%

• Communication: 4G

• Cable Length: 5m

• Input Wiring: Hardwired

• Display: LCD Screen

• Input Cord (three-phase): L1, L2, L3, N (Neutral), and PE (Protective Earth)

• Protection: Overcurrent protection, Residual current protection, Ground protection, Surge protection, Over/Under Voltage protection, Over/Under temperature protection.

• IP Rated: IP54

• Storage Temperature: -40 to 80℃

• Operating Temperature: -30℃~65℃

• Operating Humidity: 5%~95%

• Connector: 1

• Standards:

  • GB/T 18487.1-2015

  • GB/T 27930-2015

  • NB/T 33001-2018

  • NB/T 33008.1-2018

• Dimensions (H x W x D): 680 x 500 x 155mm

• Net Weight: 50.0kg

• Gross Weight: 55.0kg

• Warranty: 2 Years

Compatible With

Ideal for residential, commercial, and fleet EV charging, the Wattsaving T30 is compatible with a broad range of electric vehicle models, ensuring fast and secure charging.

Comparable To

ABB Terra 30 kW, Siemens VersiCharge Ultra (based on fast charging, safety features, and communication capabilities).

Disclaimer

Ensure proper installation according to the manufacturer’s guidelines. Specifications are subject to change without notice.
