Fe Faith AmpCore™ HQ7 Smart DC Charger – 7kW

Fe Faith AmpCore™ HQ7 Smart DC Charger – 7kW

Upgrade your EV charging setup with the FE-FAITH Wattsaving HQ7 7kW Smart DC Charger—a compact, high-efficiency solution designed for residential and light commercial use. With an impressive 94% efficiency rating and a wide output voltage range of 200–1000Vdc, this charger ensures fast and reliable charging for a wide range of electric vehicles. Equipped with smart 4G and Bluetooth connectivity, it offers seamless monitoring and remote control. Built to last, the HQ7 features an IP54-rated enclosure, a user-friendly LCD display, and comprehensive protection systems to ensure safe, long-term use in all environments.
Comparable to: Tesla Wall Connector, ChargePoint Home Flex (based on smart DC charging and communication features).

What It Does

The Fe Faith AmpCore™ HQ7 Smart DC Charger delivers fast, efficient, and reliable DC charging with a maximum output of 7kW. This charger is ideal for home or light commercial use, supporting a wide voltage range of 200–1000Vdc for compatibility with various electric vehicle models. With built-in 4G and Bluetooth connectivity, the charger offers convenient remote monitoring and control. Designed for long-term use, it features a durable IP54-rated enclosure and safety features like overcurrent and surge protection.

Key Features:

• 7kW Fast DC Charging: Delivers efficient EV power with up to 7kW output.

• Smart Communication: Integrated 4G and Bluetooth connectivity for remote monitoring and control.

• Compact & Lightweight: Easy to install in various locations with a flexible, compact design.

• Advanced Safety Protections: Includes surge, overcurrent, voltage, and temperature control to ensure safe charging.

• LCD Display Interface: Real-time charging status and data displayed for easy tracking.

Specifications:

• Model: Wattsaving HQ7

• Output DC Power: Maximum 7kW

• Input Voltage: 176~264Vac

• Output Voltage: 200~1000Vdc

• Frequency: 45-55Hz

• Current: 22A MAX

• Efficiency: ≥94%

• Communication: 4G/Bluetooth

• Cable Length: 5m/8m

• Input Wiring: Hardwired

• Display: 1.52" LCD Screen

• Input Cord (single-phase): L, N (Neutral), and PE (Protective Earth)

• Protection: Overcurrent protection, Residual current protection, Ground protection, Surge protection, Over/Under Voltage protection, Over/Under temperature protection.

• IP Rated: IP54

• Storage Temperature: -40 to 90℃

• Operating Temperature: -40℃~50℃

• Operating Humidity: 5%~95%

• Connector: 1

• Standards:

  • GB/T 18487.1-2015

  • GB/T 27930-2015

  • NB/T 33001-2018

  • NB/T 33008.1-2018

• Dimensions (H x W x D): 405 x 250 x 119mm

• Weight: 9.0kg

Compatible With

Perfect for residential and light commercial EV charging, the Wattsaving HQ7 is compatible with various electric vehicle models due to its broad voltage range and fast DC charging capabilities.

Comparable To

Tesla Wall Connector, ChargePoint Home Flex (based on smart DC charging and communication features).

Disclaimer

Ensure proper installation according to the manufacturer’s guidelines. Specifications are subject to change without notice.
