FE-FAITH Autel Energy MaxiCharger DC V2X

Unlock next-generation EV charging with the Autel MaxiCharger DC V2X—a revolutionary bi-directional charging solution delivering up to 12kW of power. Not only does it charge your electric vehicle rapidly, but it also allows you to power your home during peak hours or outages, transforming your EV into an energy asset. Designed to optimize energy usage, reduce grid reliance, and cut electricity costs, this smart charger supports both CCS1 and CHAdeMO connectors. Whether wall-mounted or pedestal-installed, its compact footprint and intelligent controls make it ideal for modern homes embracing green energy independence.

Key Features:

• Bi-Directional Power: Supports vehicle-to-home (V2H) and vehicle-to-grid (V2G) energy flow.
• Rapid EV Charging: Delivers up to 12kW for fast, reliable power replenishment.
• Smart Energy Management: Optimize usage during peak times and lower costs.
• Compact & Versatile Design: Mount to walls or install freestanding with a pedestal.
• Seamless Control: Manage settings via Autel Charge App and Autel Cloud platform.

Specifications:

• DC Output: 7kW / 12kW (CCS1 or CHAdeMO)
• Output Voltage: CCS1: 150–950V DC | CHAdeMO: 150–500V DC
• Output Current: 40A @ 300V
• AC Input: 208/240V AC, 60Hz
• Power Factor: ≥ 0.99
• Connectivity: Bluetooth, Wi-Fi, Ethernet, CAN, RS485
• Mounting Options: Wall or pedestal
• Dimensions: 711 × 386 × 170 mm
• Cable Length: 5m
• User Interface: LED/APP via Autel Charge App & Cloud
• Operating Temp Range: -25°C to +50°C

The Autel MaxiCharger DC V2X is a high-efficiency 12kW bi-directional EV charger that powers your vehicle and your home. Ideal for eco-conscious households, it delivers fast charging, grid support, and intelligent energy savings in a sleek, easy-to-install design.
