Fe Faith Forge™ Mono Resin Printer – 10K LCD Model

Fe Faith Forge™ Mono Resin Printer – 10K LCD Model

Precision meets performance in the Fe Faith Forge™ Mono 10K Resin Printer, engineered for creators who demand high resolution and compact reliability. With a powerful 10K monochrome LCD and laser-engraved build platform, this printer produces ultra-detailed models with smooth surface quality. Whether you're prototyping, designing miniatures, or crafting intricate jewelry, it delivers professional-grade output in a desktop-friendly form.

What It Does

The Forge™ Mono 10K produces ultra-high-resolution resin prints using a 7-inch 10K monochrome LCD screen and upgraded parallel matrix light source. It ensures exceptional detail, stable curing, and efficient performance in a compact form factor—perfect for high-detail model creation.

Specifications

XY Resolution: 17μm (9024 × 5120 pixels)
LCD Screen: 7” 10K Monochrome
Build Volume: 153 × 87 × 165 mm (6.0 × 3.43 × 6.5 in)
Max Print Volume: 2.2L
Print Speed: ≤ 50 mm/hr (1.97 in/hr)
Build Platform: Laser-engraved
Leveling: 4-point manual leveling
Control Panel: 2.8" TFT Touchscreen
Light Source: Upgraded parallel matrix LED
Data Input: USB
Machine Size: 230 × 235 × 391 mm (9.1 × 9.3 × 15.4 in)
Weight: 4 kg (8.8 lb)

Key Features

• Ultra-Fine Resolution: 10K LCD delivers 17μm XY detail

• Laser-Engraved Platform: Improved adhesion and stability during printing

• Compact Footprint: Desktop-friendly size with ample print volume

• Efficient Light Source: Upgraded matrix LEDs for faster curing and consistent exposure

• User-Friendly Control: 2.8” touchscreen interface with USB data input

Compatible With

Standard UV resin (405nm), ABS-like, plant-based, high-temperature, and flexible resins

Comparable To

Anycubic Photon Mono X 6Ks, Elegoo Mars 4 Ultra, Phrozen Mini 8K

Disclaimer
Ensure proper resin handling and post-processing. Printer performance may vary based on resin type and slicer settings. Always operate in a well-ventilated area.
