Fe Faith ForgeX™ EVO 22 Large Format Printer

Fe Faith ForgeX™ EVO 22 Large Format Printer
A powerful, industrial-grade 3D printer designed for professionals who need size, speed, and precision. The EVO 22 offers massive build volume and high-temperature compatibility for engineering and industrial applications.

What It Does
The Fe Faith ForgeX™ EVO 22 is engineered to meet the demands of professional 3D printing. With its huge build volume and high-temp material compatibility, it produces high-strength, accurate parts for prototypes, models, and industrial applications. The printer's heated chamber and precise extrusion system ensure excellent print quality, while its robust aluminum and steel frame provides long-term durability.

Specifications

• Shipping Weight: 150 lbs

• Shipping Dimensions: 40 × 30 × 29 in

• Extruder Configuration: G-Series High-Torque Cartridge-Style Planetary Dual Extrusion System

• Build Volume: 12" x 12" x 22.75" (305 mm x 305 mm x 578 mm)

• Max Print Speed: 100-150 mm/sec

• Heated Chamber: Yes

• Travel Speed: 125+ mm/sec MAX

• Max Extruder Temp: 315°C

• Max Bed Temp: 160°C

• Minimum Layer Height: 40 microns

• Recommended Layer Height: 180 microns or above

• Calibration: Auto-Leveling

• Materials: Over 40 materials including ABS, PC, PP, Nylons, TPE, TPU, and more

• Filament Size: 2.85 mm +/-0.10

• Nozzle Size: 0.8 mm Heavy Duty included, 1.0 mm, 0.5 mm, and 0.35 mm optional

• Weight: 75 lbs

• Dimensions: Height: 36", Width: 28", Depth: 24.5"

• Frame Construction: One-piece aluminum main frame, polycarbonate

• Motion System: Core XY

• Enclosed Print Chamber: Yes

• Heated Bed: Yes

• Print Plate Material: Borosilicate Glass, MaxGrip Composite Plate

• Cooling Fans: Dual Part Cooling, Single 60 mm Extruder

• Display: 7" Touchscreen

• Software: APEX

• Connectivity: Ethernet, USB Cable, USB Drive, Wi-Fi

• Print via Removable Device: USB Drive, USB Stick + Onboard Storage

• Maintenance Tools Included: Allen Wrenches, Micro Drill Bit Set

• Accessories Included: 0.80 Extended-Life Nozzle, Nozzle-Cleaning Tool, Wolfbite 2 oz., 2 Spools ABS, 1 USB Drive

• Filament Included: Yes

• Bed Adhesive: Wolfbite MEGA, Wolfbite NANO, Wolfbite NITRO, Wolfbite Original, Wolfbite ULTRA

• Warranty: 12 months, by manufacturer

• Email Support: tech@airwolf3d.com

• Phone Support: +1 (949) 478-2933

• Tutorials: airwolf3du.com

• Upgradeable: Yes

• Manufacturer Lead Time: 2 Weeks

• Options: Add Onsite Training with Set Up / Installation, Free Online Training

Compatible With
Fe Faith ForgeX™ EVO 22 supports a wide range of engineering and industrial-grade filaments, making it perfect for a variety of professional applications.

Comparable To
Comparable to Airwolf3D EVO 22 and Raise3D Pro2 (based on build volume, speed, material compatibility, and industrial-grade performance).

Disclaimer: Fe Faith™ products are independently engineered and not manufactured by or affiliated with Airwolf3D, Raise3D, or other third-party brands mentioned. All trademarks are property of their respective owners.
