Fe Faith PrintCore™ TAZ 8 FDM Printer

Fe Faith PrintCore™ TAZ 8 FDM Printer
A professional-grade, large-format FDM printer designed for engineers, creators, and businesses that need reliability, precision, and massive build capacity.

What It Does
The Fe Faith PrintCore™ TAZ 8 offers an expansive 295 × 295 × 285 mm print volume, all-metal hot end, and open-source hardware for full customization. It supports high-temperature filaments, advanced calibration systems, and offline printing—making it ideal for production-grade prototyping and demanding creative work.

Specifications

• Printing Technology: FFF (Fused Filament Fabrication)

• Max Build Volume: 295 × 295 × 285 mm (11.5 × 11.5 × 11.2 in)

• Tool Head: Galaxy Series Compatible

• Layer Height: 0.1 mm to 0.4 mm

• Platform Height Range: 0.05 mm to 1.8 mm

• Nozzle: 0.5 mm Nickel-Plated Brass

• Max Hot End Temp: 290°C (firmware limited)

• Axis Resolution: X/Y – 0.01 mm, Z – 0.0019 mm

• Motion System: GT2 Belt Drive, Linear Rails (X/Y), 12 mm Igus Z Rods

• Max Travel Speed: 500 mm/s (firmware limited)

• Heated Bed: 360W 24V Silicon

• Bed Temp Max: 110°C

• Bed Material: Magnetic Flex Bed

• Filament Diameter: 2.85 mm or 1.75 mm (based on head)

• Filament Sensor: Runout + Stripping Detection

• Mainboard: 32-bit Archim 2.2b w/ Trinamic TMC2130 + Xpand

• Firmware: Marlin

• Auto Bed Leveling: BLTouch 16-Point Mesh

• Calibration: Auto X-Axis Tramming, Z-Offset, Backlash Compensation

• Power Supply: 500W 24V (Mean Well, auto-switching)

• Input Voltage: 100V–240V AC

• Software: Cura LE (LulzBot Edition)

• OS Support: Windows, macOS, Linux

• File Formats: STL, OBJ, X3D, 3MF

• Print Temp Range: 5°C–45°C (41°F–113°F)

• Supported Filaments: PLA, TPU, ABS, PETG, PVA, PVB, Nylon, PC (under 290°C)

• Enclosure: Optional accessory available

• Connectivity: USB Serial, SD Card (8GB included)

• Warranty: 1 Year (optional extended coverage)

• Country of Origin: USA

Compatible With
Supports open-source slicers and firmware. Ideal for print farms, prototyping labs, engineering departments, architecture studios, and advanced hobbyists.

Comparable To
Comparable to LulzBot TAZ 6/TAZ Workhorse, Raise3D E2, and Prusa XL (based on volume, open-source support, and hardware quality).

Disclaimer: Fe Faith™ products are independently engineered and not manufactured by or affiliated with LulzBot, Raise3D, Prusa, or other third-party brands mentioned. All trademarks are property of their respective owners.
