Fe Faith SolisEdge™ 600W Wind + Solar Hybrid Kit

Fe Faith SolisEdge™ 600W Wind + Solar Hybrid Kit
A reliable and efficient off-grid power solution combining wind and solar energy for 24/7 power generation.

What It Does
The Fe Faith SolisEdge™ 600W 12V Hybrid Solar Wind Kit combines wind and solar power into one complete, sustainable off-grid solution. Featuring a 400W wind turbine and two 100W monocrystalline solar panels, this hybrid system ensures constant energy generation day and night, regardless of weather conditions. Ideal for remote areas like cabins, RVs, boats, and emergency backup systems, it provides reliable, renewable power while reducing dependence on a single energy source.

Specifications

• Wind Turbine:

  • Rated Power: 400W

  • Starting Wind Speed: 2.0 m/s

  • Rated Wind Speed: 13 m/s

  • Blade Diameter: 1.3 m

  • Rated Voltage: 24V

  • Max Wind Speed: 50 m/s

  • Weight: 5 kg

• Solar Panels:

  • Rated Power: 100W (each of 2 panels)

  • Cell Type: Monocrystalline

  • Max Voltage (Vmp): 20.2V

  • Open Circuit Voltage (Voc): 24.5V

  • Short Circuit Current (Isc): 5.2A

  • Maximum Current: 4.95A

  • Dimensions (per panel): 985 x 535 x 35mm

  • Weight (per panel): 5.2 kg

• Hybrid Charge Controller:

  • Voltage: 24V

  • Wind Turbine Power: ≤800W

  • PV Array Maximum Open Circuit Voltage: 55.2V

  • PV Array Minimum Operating Voltage: > Vbat + 1V

  • Rated Current: 40A

  • Max Wind Turbine Current: 33A

• Inverter:

  • Rated Power: 600W

  • Surge Power: 1000W

  • Output Frequency: 60Hz ± 0.2Hz

  • Efficiency: > 85%

  • Dimensions: 12" x 6.77" x 2.95"

  • Weight: 5.5 lbs

• Lithium Battery:

  • Capacity: 100Ah

  • Power: 1200Wh

  • Voltage: 12.8V

  • Max Charge/Discharge Current: 100A

  • Charge Temp Range: 0-55°C

  • Discharge Temp Range: -20°C to 55°C

  • Weight: 21 lbs

Key Features

• 600W Total Output: Provides a combination of solar and wind power to meet the energy needs of off-grid setups

• Hybrid Power Generation: Generates power from both wind and solar sources, offering continuous energy generation throughout the day and night

• Complete Kit: Includes wind turbine, solar panels, charge controller, inverter, lithium battery, cables, and mounting hardware

• Durable and Weatherproof: Designed to withstand harsh environmental conditions for long-term use

• Expandable System: Easily connect additional panels or batteries for increased energy capacity

• 12V System Compatibility: Ideal for off-grid 12V applications such as RVs, boats, cabins, and emergency backup

Included Components

• 1 x 400W Wind Turbine Generator

• 2 x 100W Monocrystalline Solar Panels

• 1 x 40A Hybrid Charge Controller

• 1 x 600W 12V Off-Grid Inverter

• 2 x 100Ah LiFePO4 Lithium Batteries

• 2 x 6AWG Battery Interconnect Cable

• 1 x 5M 12AWG Extension Cable with MC4 Connectors

• 1 x 9M 13AWG Wind Turbine Extension Cable

• 2 x Z Mounting Brackets

• 1 x Y Branch Cable MC4 Connectors

Applications
Perfect for RVs, cabins, tiny homes, boats, and any off-grid location that requires continuous power generation, with both wind and solar energy sources.
