FE-FAITH Trina Vertex 390W Solar Panel High Value

The Trina Vertex 390W Solar Panel is a powerful and affordable solution for residential and commercial solar installations. Manufactured by Trina Solar, a global Tier-1 leader known for innovation and quality, this panel offers exceptional energy yield thanks to advanced half-cut cell and bifacial technologies. With an efficiency rating of up to 21.4%, the Vertex 390W is designed to maximize sunlight absorption and reduce power loss, delivering up to 600W peak power output under optimal conditions. It features durable construction with tempered glass and an anodized aluminum frame, making it suitable for various environments.

Trina Solar’s commitment to sustainability and quality assurance is reflected in its 15-year workmanship warranty and 25-year performance guarantee. Ideal for homeowners and businesses seeking a scalable, low-maintenance solar panel with superior performance and long-term reliability.

Key Features:

• High Efficiency: Up to 21.4% efficiency with multi-busbar and half-cut cell technology
• Bifacial Design: Double glass system increases energy yield by up to 30%
• Robust Build: Tempered high-transmittance glass with anodized aluminum alloy frame
• Durability & Warranty: 15-year workmanship and 25-year performance warranty with 84.8% output at 25 years
• Reduced Power Loss: 1/3 cut cells and multi-bar design minimize resistance and enhance output
• Easy Installation: Lightweight and compact panel design for seamless mounting
• Sustainability Certified: EPD certified with a focus on reducing environmental impact

Specifications:

• Model: Trina Vertex 390W
• Panel Dimensions: 1754 x 1096 x 30 mm
• Power Output (Pmax): 390 W
• Efficiency: 21.4%
• Open Circuit Voltage (Voc): 40.8 V
• Max Power Voltage (Vmpp): 33.8 V
• Max Power Current (Impp): 11.54 A
• Short Circuit Current (Isc): 12.14 A
• Cell Type: Monocrystalline, 120 cells
• Glass Thickness: 3.2 mm, tempered with anti-reflective coating
• Frame: Anodized Aluminum Alloy
• Encapsulant: EVA
• Connector Type: MC4 compatible
• Protection Class: IP68
• Weight: Approx. 21 kg
